Type

UHF passive RFID tags

Frequency

860~960MHz

Standards/Protocols

EPC CLASS1 GEN2, ISO 18000-6C

Physical parameters

Size

75*20*3.0/56*12*1.4mm(Customized Design )

Antenna Material

PET+AL

Outer Material

Silicone Color: Black/White

Performance Parameters

Memory Size

Up to 512bit

Chip

Impinj M5/Alien H3 /Alien H4

Operating Mode

R/W

Reading Distance

0-1M/0-4M(Related to reader performance and working environment)

Environmental parameters

Operating Temp

-30~+220(Celsius)

Storage Temp

-40~+220(Celsius)

Specific applications

Applications

Washing factory, chemicals(strong acid and alkali), organic solvents, etc.

Packaging and delivery

Package

200/ pack(Customized Design)

Heat Resistance

Drying 85 C (Up to 60 min) or 220 C (Up to 30min);

Ironing 200 C (Up to 10 sec)

Humidity

-20 C to 50 C, 10% to 95%RH

Multi-tag reading

Can read large quantity of tags at the same time

Frequency

860~960MHz broadband design for global use

Wide application

Laundry management of hotels, washing, hospitals, etc.

Customized design

Size can be changed according to your need

Competitive product

High-performance with low price; reliable quality (high temperature resistance/acid and alkali resistant); quality post-sales service; fast delivery.

Certificate

CE; RoHS; EPC global
